| Body Material | PA6GFR30 |
| Maximum Working Pressure | 6 bar ; 87 Psi |
| Maximum Working Temperature | 60 °C ; 140°F |
| Sand Capacity | 200 kg |
Cleaning Process
The backwash process cleans the filter by reversing the water flow. Clean water from the rest of the system is directed into the filter’s outlet, while simultaneously, the inlet valve closes and the drain valve opens. The upward flow of water expands the sand bed, releasing trapped particles, which are then flushed out through the drain line. This procedure can be performed manually or set to occur automatically. An automatic system requires a minimum of two filters to ensure a continuous supply of clean water for the backwash cycle.
Working Principle
Sand filters work by passing contaminated water downward through a multi-layered bed of sand. As the water travels through the fine spaces within the sand media, physical and organic particles are captured and removed. At the bottom of the tank, a network of diffusers collects the purified water and sends it to the outlet, while securely hold - ing the sand media in place. The type and layering of the sand can be specifically selected to match the water quality and achieve the desired filtration level.
P30 Series - Plastic Sand Media Filters
local_offer
P30
ADVANTAGES
The Ultimate Defense Against Contaminated Water
The Aytok Media Filter is the ultimate defense against challenging water sources rich with organic matter, algae, and fine particulates. Its deep-bed filtration technology provides unparalleled purification by trapping the stubborn contaminants that other filters miss, protecting sensitive equipment across both agricultural and industrial applications. This maximizes efficiency and minimizes downtime. Engineered with a durable, noncorrosive structure and flexible manual or automatic backwash options, it is the professional’s choice for mastering the most difficult water conditions
GENERAL FEATURES
| Body Material | PA6GFR30 |
| Maximum Working Pressure | 6 bar ; 87 Psi |
| Maximum Working Temperature | 60 °C ; 140°F |
| Sand Capacity | 200 kg |
Ürün Detayı
P30 Series - Plastic Sand Media Filters
local_offer
P30
GENERAL FEATURES
Cleaning Process
The backwash process cleans the filter by reversing the water flow. Clean water from the rest of the system is directed into the filter’s outlet, while simultaneously, the inlet valve closes and the drain valve opens. The upward flow of water expands the sand bed, releasing trapped particles, which are then flushed out through the drain line. This procedure can be performed manually or set to occur automatically. An automatic system requires a minimum of two filters to ensure a continuous supply of clean water for the backwash cycle.
Working Principle
Sand filters work by passing contaminated water downward through a multi-layered bed of sand. As the water travels through the fine spaces within the sand media, physical and organic particles are captured and removed. At the bottom of the tank, a network of diffusers collects the purified water and sends it to the outlet, while securely hold - ing the sand media in place. The type and layering of the sand can be specifically selected to match the water quality and achieve the desired filtration level.
ADVANTAGES
Powerful Filtration, Smarter Design.
The Ultimate Defense Against Contaminated Water
The Aytok Media Filter is the ultimate defense against challenging water sources rich with organic matter, algae, and fine particulates. Its deep-bed filtration technology provides unparalleled purification by trapping the stubborn contaminants that other filters miss, protecting sensitive equipment across both agricultural and industrial applications. This maximizes efficiency and minimizes downtime. Engineered with a durable, noncorrosive structure and flexible manual or automatic backwash options, it is the professional’s choice for mastering the most difficult water conditions
