Single Plastic Filter with Hydrocyclone
GENERAL FEATURES
| Plastic Filter Type | Manual Disc(PSD), Vacuum Cleaning Screen(PVS) |
| Filter Body Material | PA6GFR30 |
| Disc Material | PP |
| Screen Material | SS304L,PA6GFR30 |
| Collector Material | S235JR, SS304L, SS316L, PE |
| Maximum Working Pressure | 6 bar ; 87 Psi |
| Minimum Working Pressure | 1 bar ; 14.5 Psi |
| Maximum Working Temperature | 60 °C ; 140°F |
| Backwash Operation Criteria | Pressure Difference |
| Control System | Manual |
| Filtration Sensitivity (PSD) | 20, 50, 100, 130, 200 μ (micron) |
| Filtration Sensitivity (PVS) | 20-2000 μ (micron) |
| If the collector material is S235JR | |
| Painting Method | Electrostatic Powder Coating |
| Painting Material | Epoxy Polyester |
| CODE | System | Capacity | |
|---|---|---|---|
| m³/h | GPM(US) | ||
| P7009 | 2" PLASTIC FILTER WITH 2" HYDROCYCLONE | 20-30 | 88-132 |
| P7010 | 2,5" PLASTIC FILTER WITH 2,5" HYDROCYCLONE | 30-40 | 132-176 |
| P7011 | 3" PLASTIC FILTER WITH 3" HYDROCYCLONE | 40-50 | 176-220 |
| P7011D | 3" DOUBLE PLASTIC FILTER WITH 3" HYDROCYCLONE | 50-60 | 220-264 |
| P7012 | 4" DOUBLE PLASTIC FILTER WITH 2X2,5 HYDROCYCLONE | 50-70 | 220-308 |
