| Filter Type | Metal Screen Filter(YE) |
| Filter Body Material | S235JR |
| Screen Material | SS304L, PA6GFR30 |
| Collector Material | S235JR, SS304L, SS316L |
| Maximum Working Pressure | 8 bar ; 116 Psi |
| Minimum Working Pressure | 2 bar ; 29 Psi |
| Maximum Working Temperature | 60 °C ; 140°F |
| Backwash Operation Criteria | Time and Pressure Differential Setup |
| Control System | Electronic(AC/DC) |
| Filtration Sensitivity | 20-2000 μ (micron) |
| If the collector material is S235JR | |
| Painting Method | Electrostatic Powder Coating |
| Painting Material | Epoxy Polyester |
